Signal Conditioning Amplifiers

When signals are produced by dynamically applied loads at frequencies above 0.1 Hz, or are transients, measuring instrumentation requires adequate frequency response and a wide amplifier gain range for output to the appropriate recording or display device. Such an instrument consists of an amplifier and signal conditioner with a built-in or shared power supply. Individual units are normally required for each channel when simultaneous recording or multiple channels are needed. Micro-Measurements offers three products with proven high performance and low noise in applications including impact tests, rocket motors, explosive events and engine monitoring.



Full screen preview



Full screen preview



Full screen preview

      2100   2200   2300



Frequency Response

    DC 50 kHz (–3 dB)   DC 50 kHz (–0.5 dB)
DC 100 kHz (–3 dB)
  DC 60 kHz ( –0.5 dB)
DC 145 kHz (–3 dB)


Output (±)

    10V @ 100mA   10V @ 10mA and
1 VRMS @ 10mA
  10V

Amplifier Gain     Continuously Variable
1 – 2100
  Continuously Variable 1 – 3300   Continuously Variable
1 – 11,000


Bridge Excitation

    DC: 0.5-12V   DC: 0.5-15V or
0.5-30 mA
  DC: 0.7-15V (11 steps) 0.2-7V Variable


Input Power

    AC   AC   AC


Remarks

    High Performance Amplifier for Simultaneous Dynamic Recording   High Performance, for Demanding Environments   High-Frequency Response Multi-Feature Signal Conditioner






2100


2100 is a high performance but simple amplifier. Up to 10 channels in a rack share a common power supply. Setup is simple and intuitive, with front-panel manual controls for bridge excitation, user-definable shunt calibration, and a gain multiplier and Vernier adjustment from 1 to 2100.



2200


2200 offers individual power supplies for improved channel-to-channel separation. It offers a wider gain range, high frequency response, automatic balance control and constant voltage or current excitation. It is ideal for harsh environment measurements, with a common-mode input of up to +/-350 volts, and a driven-guard shield connection for improved environmental noise rejection over conventional ground shield connection systems.

2300


2300 is the choice for impact and other high-speed transient events such as split Hopkinson bar and explosive tests. Separate power supplies per channel, very high frequency response and ultra-wide gain and automatic balance, 4-step user-definable shunt calibration, user-definable filters as well as switchable AC coupling make this a versatile and high-performance amplifier.
