Tee Pattern Strain Gages: Multiple Sensors - One Backing

They are used where direct tension measurements, such as a bolt in tension or suspension rod in compression, is desired. A full bridge in this situation minimises pickup due to bending. Tee rosettes can also be deployed for bending measurements, especially useful on large infrastructure such as wind turbine towers.



Adjacent gauges on the same backing will see identical temperature and therefore eliminate thermal outputs due to differential temperatures across the structure. Additionally, 45° alignment marks are provided on each T-Rosette gage so it may be accurately applied to a shaft to measure torsion. Refer to TechNote 515.



CEA Series Tee Rosette Strain Gages















































































          [in/mm]   [in/mm]   [in/mm]   [in/mm]



Configuration



Pattern   Res. [Ω]

Gage

Length



Gage

Width



Matrix

Length



Matrix

Width

  Standard STC

Temperature Range

  Options

Tee Rosette Strain Gage 062UTA

120,

350



0.062

[1.57]



0.080

[2.03]



0.31

[7.9]



0.31

[7.9]





00, 03, 05,

06, 09, 13





–100° to +350°F

(–75° to +175°C)





 P2, SP11


  125UTA

120,

350



0.125
[3.18]



0.165
[4.19]



0.42
[10.7]



0.45
[11.4]



  250UTA

120,

350



0.250
[6.35]



0.290
[7.37]



0.48

[12.19]



0.40

[10.16]





































Stacked Tee Rosette Strain Gage 032WT   120

0.032
[0.81]



0.060
[1.52]



0.30
[7.6]



0.30
[7.6]



062WT

120,

350

  0.062
[1.57]
  0.120
[3.05]
  0.33
[8.4]
  0.33
[8.4]


  125WT

120,

350

  0.125
[3.18]
  0.180
[4.57]
  0.42
[10.7]
  0.42
[10.7]


  250WQ

350




































                              Temperature Range
Typically used with: M-Bond 200 Kit   Room temperature instant curing strain gage adhesive    –25° to +150°F (–30° to + 65°C)

M-Bond AE-10 Kit   Two-component, 100%-solids epoxy system for general purpose strain gages
Room temperature cure, highly resistant to moisture and most chemicals
  –320° to +400°F (–195° to +204°C)

  M-Bond 600 Kit    Two-component, solvent-thinned, epoxy-phenolic strain gage adhesive for high-performance    –452° to +500°F (–268° to +260°C)





EA Series Tee Rosette Strain Gages























































          [in/mm]   [in/mm]   [in/mm]   [in/mm]
Configuration Pattern   Res. [Ω]

Gage

Length



Gage

Width



Matrix

Length



Matrix

Width

  Standard STC    Temperature Range   Options

Tee Rosette Strain Gage 030TU   120

0.030

[0.76]



0.044

[1.12]



0.25

[6.4]



0.25

[6.4]





00, 03, 05,

06, 09, 13





 –100° to +350°F   (–75° to +175°C)





E, EL, P, W, SP11


  030TY   120

00.030

[0.76]



0.044

[1.12]



0.30

[7.6]



0.15

[3.8]



  050TGA   350

0.050

[1.27]



0.070

[1.78]



0.34

[8.6]



0.17

[4.3]



  062TJA   350

0.062

[1.57]



0.080

[2.03]



0.38

[9.7]



0.19

[4.8]



  062TTA

120,

350



0.062

[1.57]



0.075

[1.91]



0.28

[7.1]



0.26

[6.6]



  062TZA

350



0.062

[1.57]



0.075

[1.91]



0.28

[7.1]



0.26

[6.6]



  125TB   350

0.125

[3.18]



0.150

[3.81]



0.36

[9.1]



0.44

[11.2]



  125TG   350

0.125

[3.18]



0.150

[3.81]



0.59

[15.0]



0.21

[5.3]



  250TM

120 ,

350



0.250

[6.35]



0.300

[7.62]



0.53

[13.5]



0.75

[19.1]





































                              Temperature Range
Typically used with: M-Bond 200 Kit   Room temperature instant curing strain gage adhesive    –25° to +150°F (–30° to + 65°C)

M-Bond AE-10 Kit   Two-component, 100%-solids epoxy system for general purpose strain gages
Room temperature cure, highly resistant to moisture and most chemicals
  –320° to +400°F (–195° to +204°C)


M-Bond 600 Kit



Two-component, solvent-thinned, epoxy-phenolic strain gage adhesive for high-performance

   –452° to +500°F (–268° to +260°C)





WK Series Tee Rosette Strain Gages























































          [in/mm]   [in/mm]   [in/mm]   [in/mm]
Configuration Pattern   Res. [Ω]

Gage

Length



Gage

Width



Matrix

Length



Matrix

Width

  Standard STC    Temperature Range   Options

Tee Rosette Strain Gage 062TT   350

0.062

[1.57]



0.075

[1.91]



0.28

[7.1]



0.26

[6.6]





00,03,05,

06,09,13





 –452° to +550°F  (–269° to +290°C)





W, SP11


  125TB   1000

0.125

[3.18]



0.150

[3.81]



0.36

[9.1]



0.44

[11.2]



  125TM   350

0.125

[3.18]



0.150

[3.81]



0.36

[9.1]



0.43

[10.9



  125TQ   1000

0.125

[3.18]



0.150

[3.81]



0.42

[10.7]



0.47

[11.9]



  250TB   1000

0.250

[6.35]



0.300

[7.62]



0.63

[16.0]



0.81

[20.6]



  250TM   350

0.250

[6.35]



0.300

[7.62]



0.53

[13.5]



0.75

[19.1]
















































                              Temperature Range
Typically used with: M-Bond 200 Kit   Room temperature instant curing strain gage adhesive   –25° to +150°F (–30° to + 65°C)

M-Bond AE-10 Kit   Two-component, 100%-solids epoxy system for general purpose strain gages
Room temperature cure, highly resistant to moisture and most chemicals
   –320° to +400°F (–195° to +204°C)

M-Bond 600 Kit    Two-component, solvent-thinned, epoxy-phenolic strain gage adhesive for high-performance    –452° to +500°F (–268° to +260°C)




C2A Series Tee Rosette Strain Gages























































          [in/mm]   [in/mm]   [in/mm]   [in/mm]
Configuration Pattern   Res. [Ω]

Gage

Length



Gage

Width



Matrix

Length



Matrix

Width

  Standard STC    Temperature Range   Options

Gages With Pre-attached Cables 062LT   120 , 350

0.062

[1.57]



0.070

[1.78]



0.21

[5.3]



0.29

[7.4]





06, 09, 13





 –60° to +180°F   (–50° to +80°C)








  125LT   120 , 350

0.125

[3.18]



0.150

[3.81]



0.29

[7.4]



0.40

[10.2]






























































                              Temperature Range
Typically used with: M-Bond 200 Kit   Room temperature instant curing strain gage adhesive   –25° to +150°F (–30° to + 65°C)

M-Bond AE-10 Kit   Two-component, 100%-solids epoxy system for general purpose strain gages
Room temperature cure, highly resistant to moisture and most chemicals
  –320° to +400°F (–195° to +204°C)

M-Bond AE-15 Kit   Two-component, 100%-solids epoxy system for general purpose strain gages
Room temperature cure, highly resistant to moisture and most chemicals
   –320° to +200°F (–195° to +95°C)
