At Micro-Measurements, we specialize in delivering high-precision strain gage (gauge) instrumentation that meets the unique demands of professionals across the automotive, aerospace, civil engineering, and industrial sectors. Our strain measurement systems provide unparalleled accuracy, ensuring reliable data acquisition for critical applications.
Whether you're measuring structural stress in aircraft, monitoring strain in bridges, or testing material strength in industrial machinery, Micro-Measurements offers solutions designed to address your most complex challenges. With over 50 years of expertise, we are committed to enhancing performance and accuracy in every strain gage (gauge) measurement.
Core Features of Micro-Measurements Strain Gage Instruments:
- High Accuracy & Stability: Our systems deliver precise, consistent readings, ensuring reliable data over long periods.
- Advanced Data Acquisition: Seamlessly collect and analyze data with our StrainSmart software, optimized for complex strain gage (gauge) installations.
- Modular & Scalable Solutions: Customize your system to fit your specific requirements, from small-scale research projects to large industrial installations.
- Easy Integration: Compatible with a wide range of sensors and external systems, making integration into your existing workflow seamless.
- Real-Time Monitoring: Benefit from immediate feedback on strain measurements, allowing for real-time decision-making in critical environments.
Industry Applications for Strain Measurement Instruments
In the automotive industry, our instruments are essential for testing vehicle components under real-world conditions, helping to ensure both safety and optimal performance. For aerospace applications, our strain gages (gauges) deliver the precision needed for critical tasks, from aircraft fuselage testing to space exploration, supporting mission success in demanding environments.
In civil engineering, our systems enhance structural health monitoring of bridges, tunnels, and buildings with accurate, real-time strain measurements, contributing to public safety and infrastructure longevity. Within industrial manufacturing, our solutions monitor strain during key processes like welding, safeguarding product integrity and quality through consistent quality control.
|
|
|
|
|||||
| MultiDAQ | D4 | P3 | |||||
|
Measurement Range |
±16,000 µƐ @ GF=2.00 | ±31,000 µƐ @ GF=2.00 | ±31,000 µƐ @ GF=2.00 | ||||
|
Connection |
RJ45 | RJ45 | Terminal Block or TIO | ||||
| Input Type | Strain Gage | Strain Gage | Strain Gage | ||||
|
Bridge Types |
¼ , ½ , Full Bridge | ¼ , ½ , Full Bridge | ¼ , ½ , Full Bridge | ||||
|
Bridge Completion |
120Ω, 350Ω, 1000Ω, internal HB 1KΩ | 120Ω, 350Ω, 1000Ω, internal HB 1KΩ | 120Ω, 350Ω, 1000Ω, internal HB 1KΩ | ||||
|
A/D Converter |
24 bit Delta-Sigma | 24 bit Delta-Sigma | 24 bit Delta-Sigma | ||||
| Max. Input | ±8 mV/V @ GF = 2.0 |
±15.5 mV/V @ GF = 2.0 |
+/-15.5mV/V @ GF = 2.0 |
||||
|
Resolution |
1µƐ @ GF=2.00 | 1µƐ @ GF=2.00 | 1µƐ @ GF=2.00 | ||||
| Accuracy | 1% of reading @GF=2.0 | 0.1% of reading ±3 counts |
0.1% of reading ±3 counts |
||||
|
Excitation |
2.5 Volts (nominal,fixed) | 1.5 Volts (nominal,fixed) | 1.5 Volts (nominal,fixed) | ||||
|
Power source |
USB only | USB only | USB, battery, or DC Input | ||||
|
Data Rate (Samples per second) |
80 S/s | 8 S/s | 1 S/s | ||||
| Max. Storage | PC dependent | PC dependent | 32GB SD card or PC | ||||
| Max. Channels (multiple units) | 12 | 24 | 24 | ||||
| Software | Windows based | Windows based | Windows based | ||||
|
Drivers |
Labview, .NET interface | Labview, .NET interface | Labview, .NET interface |
The P3 Strain Indicator and Recorder
The P3 Strain Indicator and Recorder is a portable, battery-operated instrument. It can accept up four inputs from quarter, half, and full bridge strain gage (gauge) circuits, including strain-gage-based transducers. Front-panel lever operation terminal blocks enable fast connection and reconfiguration, and the TIO option adds high-quality Transducer Input connectors. A highly stable measurement circuit, regulated bridge excitation supply, and precisely settable gage (gauge) factor enable measurements of ±0.1% accuracy and 1 microstrain resolution. The P3 can be operated stand-alone via the membrane switch front panel or from the supplied software though USB to a PC.
The Model D4 Data Acquisition Conditioner
The Model D4 Data Acquisition Conditioner is a USB-powered instrument that connects to a personal computer. It can accept up four inputs from quarter, half, and full bridge strain gage (gauge) circuits via RJ45 connectors. A highly stable measurement circuit, regulated bridge excitation supply, and precisely settable gage (gauge) factor enable measurements of ±0.1% accuracy and 1 microstrain resolution. Operation is via the supplied software and can operate up to six D4s concurrently for up to 24 channels.
The MultiDAQ or StudentDAQ
The MultiDAQ is a unique and simple single-channel device. Whilst it does not have the advanced features of its multi-channel siblings, it enables quick measurements with a minimum of setup. Strain gage (gauge) inputs (quarter, half, and full bridge) can be connected via the RJ45 connector and set up with the supplied software. Measurement units can be microstrain or user-defined for load or displacement measurements, and up to twelve devices can be operated at the same time. The internal quarter bridge resistance is fixed; three versions are available for 120, 350, or 1000 Ω inputs.
Learn more about the MultiDAQ / StudentDAQ
Ready to take your strain measurement capabilities to the next level? Contact our team today to request a demo, speak with a sales expert, or visit our comprehensive guide to find the perfect solution for your application.
